High Efficient Condenser,Water Condenser,Shell And Tube Condenser For Sea Water
Work Condition:
1) Refrigerant side(In the shell): R22,R134a,R407c,R410a etc.
2) Water side (In the tube):Nature water,sea water,salt water or other corrosive solution.
3) Capacity from 11KW~500KW
Material:
1) Heat transfer Tube: Copper alloys, Al-Brass,Cupro-Nickel, titanium
2) Shell: Carton steel.
Features:
1) Usually used for heating.
2) Th heat exchanger tube has super strong corrosion proof ability and high intensity,was tested by 1.0 MPa pressure to make sure the tube is strong and not leakage .
3)The shell was tested by 2.8Mpa water pressure to make sure the water system not leakage
| Technical Data |
| Model | Capacity | Flow Rate | Materials |
| KW | M³/H | Outer Shell | Inner Tube | Tube Size |
| WHT-WN10 | 35 | 7.7 | Carbon steel | Copper | 15.88*1.1 |
| External Dimensions (mm) |
| Model | D | A | A1 | B | E | F | H | S | S1 |
| WHT-WN10 | 168 | 1110 | 1000 | 600 | 200 | 150 | 313 | 80 | 80 |
| Connector (mm) |
| Model | Water Inlet / Outlet | Gas Inlet | Gas Outlet | Fusible Plug |
| W | a | b | c |
| WHT-WN10 | Rp1-1/2 | ￠22 | ￠16 | 3/8 |
| Working Condition |
| | Shell Side | Tube Side |
| Design pressure (Mpa) | 2.3 | 0.8 |
| Test pressure (Mpa) | 2.65 | 1.0 |
| Max. pressure (Mpa) | 2.3 | 0.8 |
| Design temperature (°C) | 50 | 38 |
| Working Medium | R404A | FRESH WATER |
Application:
Manufacture 35 kw Shell And Tube Condenser Sea Water Copper Condenser For Marine, can be supporting the use of frozen and refrigerated .
PACKAGE:
Wooden case packing.
DELIVERY TIME:
8-15days after confirming order,detail delivery date should be decided according to
production season and order quantity.
Wenzhou Wuhuan Refrigeration Accessories Factory designs and manufactures a wide
range of heat exchangers for refrigeration, industrial and special applications .
Our evaporators and condensers can be manufactured with different materials and can
work with all types of fluids and with duty up to 6000 kW.
Product Category:
FAQ
Are you factory?
Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
What information needed if I want a quotation?
Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
When can I get the price?
We usually quote within 8 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
